******** Audi TTS Quattro Coupe (8J3) L4 2.0 L Turbo (CDMA) Techniques de DIAGNOSTIC ET de RÉPARATION # 481230 Date: 120625


Volant - Volant Cuir Dommages



48 volant cuir dommages, tous les véhicules



48 12 30



2028220/2



Juin 25, 2012Remplace le Bulletin de Service Technique du Groupe de 48 numéro 11 - 18 en date du 7 décembre 2011 pour les raisons énumérées ci-dessous.



Véhicules Concernés



Condition



Volant endommagé.



De Formation Technique



19



Optique des dommages sur le volant (Figures 1 et 2) n'est pas sous garantie. De nombreuses enquêtes ont montré qu'il n'y a aucun défaut de matériau ou de



de fabrication. Le dommage est causé par l'impact externe, par exemple le contact avec les ongles, les fermetures à glissière, montres, bagues, etc.



La Solution De Production De



Non Applicable.



Service



Non Applicable.



GarantieCe dommage est dû à une influence extérieure et n'est couvert par aucune garantie Audi.



Des Informations Supplémentaires



Toutes les pièces de service et les références fournies dans ce BST sont sujettes à modification et/ou suppression. Toujours vérifier auprès de votre Département des Pièces et service



manuels pour les informations les plus récentes.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 2328


YES



The measurement value is OK.Cause



- Control module has an internal error.



REMEDY



- Disassemble and assemble automatic transmission using the repair instructions.



- Exchange electrohydraulic control unit.



IMPORTANT NOTEFollowing the repair measures, the following checks MUST be carried out using the Diagnosis Assistance System, menu



'Control unit adaptations'



- Flash programming of control unit Y3/8n4 (Fully integrated transmission control (VGS) control unit)



- SCN coding



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has open circuit.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has short to ground.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



Further image can be displayed with key F7.X11/4 (Diagnosis test connector)Test sequence



- Switch off ignition.



- Separate plug connection at transmission.



- Measure voltage in transmission wiring harness using a multimeter.



- Measure resistance with multimeter between 3 and 11 (X11/4)



Specified value



- Resistance measured: [< 0,6] ohms

New York Passes Country’s Biggest Fine For Loud Exhausts

Straight pipe at your own risk.

2022 Honda Civic Review, Pricing, and Specs

2022 Honda Civic Review, Pricing, and Specs: Honda's popular Civic compact car gets a big glow-up for the 2022 model year as it debuts a more grown-up ...

******** Audi A6 Limousine (4F2) V6-3.2 L (CALA) Technische DIAGNOSE-UND REPARATUR # 481230 Datum: 120625


Lenkung - Lenkrad Leder-Schaden



48-lenkrad Leder-Schaden, alle Fahrzeuge



48 12 30



2028220/2



Juni 25, 2012Ersetzt Technische DIAGNOSE-UND REPARATUR-Gruppe 48 Nummer 11 - 18 vom 7. Dezember 2011 für die nachfolgend aufgeführten Gründen.



96



Betroffene Fahrzeuge



Zustand



Lenkrad beschädigt.



Technischer Hintergrund



Optische Schäden am lenkrad (Abbildungen 1 und 2) nicht unter die Garantie. Zahlreiche Untersuchungen haben gezeigt, dass es keine Fehler in material oder



Verarbeitung. Der Schaden durch äußeren Einfluss, z.B. Kontakt mit dem finger, Nägel, Reißverschlüsse, Uhren, Ringe usw.



Produktion Lösung



Nicht Anwendbar.



Service



Nicht Anwendbar.



97



GarantieDiese Schäden durch äußere Einflüsse und nicht von einem Audi-Garantie.



Weitere Informationen



Alle Teile und service-Verweise in dieser TSB unterliegen, zu ändern und/oder entfernen. Überprüfen Sie immer mit Ihrem Teile-und service-Abteilung



Handbücher für die neuesten Informationen.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1395


- If fault occurs again:Check alternator.Communication with ECU required



- The quiescent current is too high.Test quiescent current.



NO



Figure legend 1:N71 (Headlamp range adjustment control module)Figure legend 2:N10/1 (Driver-side SAM control unit with fuse and relay



module)Test prerequisite



- The relevant actual value is not okay.



- Battery voltage is OK.



- Fuse N10/1f52 (Fuse 52) is OK.



Test sequence



- Switch off ignition.



- Disconnect connector at component N71 (Headlamp range adjustment control module).



- Measure direct voltage with multimeter between sockets (N71) 20 and (N71) 19



- Switch on ignition.



Specified value:Voltage = [11.0...14.5] VQuestion



- Is the measurement value OK?

2022 Honda Accord Review, Pricing, and Specs

2022 Honda Accord Review, Pricing, and Specs: Although SUVs and crossovers are the people haulers these days, we think those folks are missing out by not ...

Woman Puts On Drifting Clinic In Between Gas Station Pumps

Please don't try this.

VW ID.5 GTX Teased Ahead Of November 3 Premiere

We're just a few days away from seeing the high-performance Volkswagen ID.5

Volvo Increases Range Of Its EV With OTA Updates

Volvo takes on the future.

2022 Honda Civic Si Review, Pricing, and Specs

2022 Honda Civic Si Review, Pricing, and Specs: The 2022 Honda Civic Si is arguably the sweet spot in the brand's small-car line, with a near-perfect ratio of ...

Unique Chevy 789 Merges Three Models From The 1950s

The idea's peculiar but the execution's superb.

Chevrolet's 1,004-Horsepower ZZ632 Crate Engine Won't Come Cheap

That's a huge price to pay for a powerful (and massive) crate engine.

MyChevrolet App Reveals 2022 GMC Hummer EV's 334 Miles Range

That's a tad short of what was announced, but it isn't official just yet.

2022 Lamborghini Countach Caught Out In The Open

Deliveries of production units will start in the first quarter of 2022.

Toyota Land Cruiser Overland Camper Wants To Travel Around The World

They've reached Alaska recently. Now we wait for their next destination.

******** Audi TTS Quattro Coupe (8J3) L4-2.0L Turbo (CDMA) Technical DIAGNOSIS AND REPAIR # 871123 Date: 110920


A/C - Refrigerant Circuit Cleaning Procedure



87 Cleaning of the air conditioning refrigerant circuit



87 11 23



2018162/3



September 20, 2011.



Supersedes Technical Service Bulletin Group 87 number 08 - 13 dated December 5, 2008 for reasons listed below.



Affected Vehicles



Condition



Repeat repairs of air conditioning system. Debris was dispersed throughout the refrigerant circuit after air conditioning component damage. During



the first repair, the refrigerant circuit was not thoroughly cleaned. The debris has contaminated the new components.



Technical Background



In cases where an air conditioning system component (such as a compressor or other system component) has failed and debris from the compressor



or component is circulated throughout the refrigerant circuit, the refrigerant circuit must be cleaned of any and all debris or damage to the



replacement components will result.



The cleaning method until now has been disassembly of each part of the refrigerant circuit, blowing out the debris with compressed air, and drying



the components with nitrogen. This was ineffective for this purpose and labor intensive. A more thorough and less time consuming method is



flushing the circuit with refrigerant.



82



Production Solution



Not applicable.



Warranty



Required Parts and Tools



All parts and service references provided in this TSB are subject to change and/or removal. Always check with your Parts Department and service



manuals for the latest information.



Service



Service



Tools



83



Use the ROB134APF Air Conditioning Service System with VAS 6337/1A Air Conditioning System Flushing Device for effective refrigerant



handling and air conditioning circuit flushing after air conditioning component failure.



Now air conditioning system refrigerant recovery, evacuation, recharge and refrigerant circuit cleaning after component failure can be performed



with a single servicing station.



The VAS 6338/1 Adapter Set for Refrigerant Circuits. Along with an additional adapter (VAS 6338/33 for the front expansion valve bypass for the



Audi Q7) this kit contains the adapters necessary to complete a thorough flush operation of a contaminated circuit.



ElsaWeb contains the technical information for each model regarding the necessary adapter applications and connections of the servicing station for



the flush operation. See Elsa Web >> Heating, Ventilation Air Conditioning >> Refrigerant R134A-Servicing >> 87 Air Conditioning >>



Refrigerant Circuit >> Refrigerant Circuit, Flushing with Refrigerant R134A.



All other refrigerant recovery, evacuation and recharge operations are performed using the usual procedure specified in ElsaWeb. An operations



manual will accompany each servicing station that will describe operation of the unit.



Procedure



1. If an air conditioning component has been diagnosed as the root cause of the failure and this component is suspected of releasing debris through



the circuit, continue the diagnosis to determine if this is the case.



2. Turn the power to the servicing station on and begin by recovering the refrigerant from the system through the normal service fittings.



Tip: During the entire process avoid interrupting the power to the station. The stations internal memory will keep a log of all operations and can



conveniently be recalled and printed. If the power is interrupted, the station will lose the memory of the process, and the oil volume recovered, oil



volume added, refrigerant volume recovered, etc. will have to be manually determined.



3. Disconnect the service hoses. The VAS 6338/1 adapters will be used to bypass the following:



^ Compressor.



^ Receiver drier (depending on model).



^ Expansion valve.



If vehicle is equipped with a restrictor, remove the restrictor and reconnect the line.



84



4. Once the appropriate adapters are in place, connect the service station to the vehicle through the air conditioning compressor hoses. The flushing



attachment ports are labeled on the flusher.



This connection strategy allows for a system flush in the opposite direction of the normal refrigerant flow.



85



The flush program will begin with an evacuation of the system and a rate of rise test. This is necessary to test the integrity of the connections



before the flush cycles begin. If the rate of rise test passes, the program will proceed into the flush cycles. These cycles will occur automatically in



succession.



86



The debris is then rinsed from the circuit and contained within the filtration in the flusher. After the flush program, the system will be evacuated.



5. After the system is evacuated, disconnect the station.



Audi Q7 with four zone climate control



If the vehicle is an Audi Q7 with four zone climate control, the flush process will be repeated for the additional air conditioning unit in the rear



according to the repair information in ElsaWeb.



1. Separate the front and rear air conditioning Systems for individual rinse operations.



The VAS 6338/1 contains the necessary adapters to separate the systems for the individual rinse operations.



87



2. Bypass the rear expansion valve with an adapter from the VAS 6338/1.



3. When complete, remove any adapters that were installed from the VAS 6338/1.



4. Install components in need of replacement.



5. Connect the station in the usual manner through the service fittings and perform the normal evacuation, oil fill and refrigerant recharge operations.



6. Recall and print a log of the job. Attach the log to the repair order.

This Is What The Next-Gen Ford Fusion/Mondeo Might Look Like

Does the future look promising for the Ford Fusion?

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1767


Test voltage supply of circuit 30.



Test sequence



- Measure direct voltage with multimeter between sockets [ F.2 ] 98 and [ F.16 ] 112 of the 35-pole socket box tester.



- Switch on ignition.



Specified value



- Voltage[11.0...15.0] V



Question



- Is the measurement value OK?



YES



The measurement value is OK.End of test



NO



The measurement value is not OK.Possible cause and remedy



- F34f42 (Fuse 42)



- Lines



End of test



1.1.3.2.1.3.3. Test current consumption of component N10/1kR (Circuit 87 relay, engine).



Connect socket box to component N3/10 (ME-SFI [ME] control unit).

Toyota’s Official Car Museum Just Added A Honda To Its Collection

Even Toyota celebrates their competitor's milestones

Ferrari GTC4 Lusso AWD powerful and luxurious grand touring cars

Ferrari GTC4Lusso:Ferrari may be famous for their supercars, but the company is also adept at making powerful and luxurious grand touring cars.

Saturday, October 30, 2021

******** Audi A4 Quattro Wagon (8K5) L4 2.0 L Turbo (CAEB) Bulletin de Service Technique # 571160 Date: 111021


Keyless Systèmes Clé En Mémoire Les Paramètres Ne Sont Pas Disponibles57 Personnalisée des paramètres de la mémoire de la clé ne sont pas disponibles



57 11 60



2019958/6



Le 21 octobre 2011.



Remplace le Bulletin de Service Technique du Groupe de 57 10 - 35 en date du 18 octobre 2010 pour les raisons énumérées ci-dessous.



317



Véhicules Concernés



Condition



Le client peut signaler que personnalisée des paramètres de la mémoire (par exemple, électrique des rétroviseurs extérieurs, mémoire pour le siège, radio, climatisation, électricité



volant, etc.) sont inopérantes ou incorrectement attribué lors de l'utilisation de la touche de la télécommande.



De Formation TechniqueLes paramètres de la mémoire pour chaque clé sont stockés dans le contrôle individuel de l'unité (selon la fonction) et non pas dans la clé elle-même.



Seuls l'identification de la actuellement utilisé à distance de la clé est transmise sur le bus can. Chaque participant de l'unité de contrôle établit ses propres réglages.



La Solution De Production De



Non applicable.



Service



Pour écarter la clé de la cause, vérifiez si la touche de la télécommande est correctement identifié par le véhicule.



Astuce: des clés sur les positions 1 à 4 sont inclus dans l'personnalisée des paramètres de la mémoire de fonctions. Les clés de la position 5 ne peut pas être personnalisé.^ A3, TT, R8: Vérifier MVB 10 dans le confort unité de commande (adresse de mot 46).



^ A4 (B7), A4 Cabriolet: Vérifier MVB 7 dans le confort unité de commande (adresse de mot 46).



^ A4 (B8), A5, Audi Q5: Vérifier MVB 10 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A6 (C6), Audi Q7: Vérifier MVB 11 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A8 (D3): Vérifier MVB 6 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A6 (C7), A8 (D4): Vérifier MVB 10 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



318Si l'identification de la clé est affichée correctement, la clé est l'exploitation aux spécifications du fabricant.



La cause de la condition doit donc être trouvé dans l'un des participants, des unités de contrôle.



Garantie



Cette BST est d'information uniquement et ne s'applique à aucune garantie Audi.



Des Informations Supplémentaires



Toutes les pièces de service et les références fournies dans ce BST sont sujettes à modification et/ou suppression. Toujours vérifier auprès de votre Département des Pièces et service



manuels pour les informations les plus récentes.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1616


REMEDY



- Disassemble and assemble automatic transmission using the repair instructions.



- Exchange electrohydraulic control unit.



IMPORTANT NOTEFollowing the repair measures, the following checks MUST be carried out using the Diagnosis Assistance System, menu



'Control unit adaptations'



- Flash programming of control unit Y3/8n4 (Fully integrated transmission control (VGS) control unit)



- SCN coding



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has open circuit.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has short to ground.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



Further image can be displayed with key F7.X11/4 (Diagnosis test connector)Test sequence



- Switch off ignition.



- Separate plug connection at transmission.



- Measure voltage in transmission wiring harness using a multimeter.



- Measure resistance with multimeter between 3 and 11 (X11/4)



Specified value



- Resistance measured: [< 0,6] ohms



Question



- Is the measurement value OK?

Mercedes-AMG Confirms New GT Coupe Is Coming To Join SL

A tale of two coupes.

Bentley Flying Spur Hybrid Covers 455 Miles In One Trip Using Only Renewable Energy

That's a lot of range.

Nissan GT-R 1600hp v 1000hp v 650hp Drag Race

How much does horsepower matter?

マニュアルの最新情報です。******** Audi A6アトロセダン(4F2)V6-3.0L SC(CCAA)技術的な診断-補修#191228日:120109


冷却Sysます。 低冷却水警告および冷却水漏れ



19ラジエータ漏洩



229



19 12 28



2028397/1



月9,2012年.



影響を受け車両



条件



^低冷却水警告します。



^冷却水漏れからラジエーターです。



技術的背景



雨漏りクーラー用充電器の冷却回路のエンジンのラジエーターが漏れます。



制作のトータルソリューション



該当ありません。



サービスがある場合は冷却残渣のいずれかのクーラー用充電器の冷却回路(図1、13日)またはエンジンのラジエータ(図1、15日)に従ってください以下



手順:



1. ディスポーザブルプラスチックすべての冷却残渣の水を使用)です。



2. トポンプ-圧送液システムです。



3. 持ちエンジンで発熱する場合があります。



4. 圧冷却システムの1つのバーがあります。



5ます。 を同定するラジエーターで雨漏りが発生しています。



6ます。 交換の漏洩ラジエーターです。



保証



このTSBは情報ならないでくださいずれかに該当するAudi保証が付いています。



230



追加情報すべての部品およびサービスを参照のこTSBしに変更又は削除します。 必ず確認してくださいお部品部門、サービス

2022 Honda HR-V Review, Pricing, and Specs

2022 Honda HR-V Review, Pricing, and Specs:Text While many subcompact SUVs rely on quirky styling to attract customers, the 2022 Honda HR-V appeals to ...

2022 Honda Civic Type R: What We Know So Far

2022 Honda Civic Type R: What We Know So Far: The 2022 Honda Civic Type R will look more reserved than its over stylized predecessor, but that shouldn't ...

2022 Ford F-150 Will Be Up To $2,280 More Expensive

Another price hike for the Ford F-150.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 477


- Voltage[11.0...15.0] V



Question



- Are the measurement values OK?



YES



The measurement values are OK.Further possible causes of fault



- Test voltage supply of circuit 30.



NO



The measurement values are not OK.Possible cause and remedy



- N10/1f43 (Fuse 43)



- N10/1f44 (Fuse 44)



- N10/1kI (Circuit 87 relay, engine)



- Lines



- N10/1 (Driver-side SAM control unit with fuse and relay module)



End of test



1.4. Test current consumption of component N10/1kR (Circuit 87 relay, engine).



Connect socket box to component N3/10 (ME-SFI [ME] control unit).



Figure legend



- A -ConnectionTest cable 35-pin socket box



- 001 -Sockets of component N3/10 (ME-SFI [ME] control unit)



- 05 -35-pin socket box



- 050 -126-pin socket box



- 108 -Test cable 266 589 01 63 00



- N3/10 (ME-SFI [ME] control unit)



- II 1-63ConnectionTest cable



- III 64-126ConnectionTest cable



Warning!



-



- Connection A of test cable 108 may NOT be connected to connection B of the 126-pin socket box (050).



Continue to test with button F2

2022 GMC Yukon Review, Pricing, and Specs

2022 GMC Yukon Review, Pricing, and Specs :Outside of a Savana passenger van, nothing in the GMC truck lineup simultaneously hauls people and cargo as ...

2022 Lexus LS gets slight updates, more options

Lexus' flagship sedan gets a few updates, but don't go looking for it on the outside.

2022 Toyota GR86 Base Model In Japan Rides On Steel Wheels

Just how basic is the base Toyota GR86?

******** Audi TTクアトロロードスター(8J9)L4-2.0Lターボ(CCTA)技術的な診断 -補修#420901日:090602


サスペンションリヤサスペンションランブル/ノイズのラトル



42ランブルはラトルズリヤ



42 09 01



2020759/1



月2、2009年



影響を受け車両



133



条件ランブルはラトルからノイズリヤホイールを停止します。



技術的背景



ゆったり石ガード下部のトレーリングアームです。



制作のトータルソリューション



サービス



トの改善石ガードより強く付着後下末尾武器です。



保証



必要な部品やツール



追加情報



すべての部品およびサービスを参照のこTSBしに変更又は削除します。 必ず確認してくださいお部品部門、サービス

2023 Honda Civic Type R Spied In Another Workout At The Nurburgring

Two prototypes were spotted, both sounding mean and lean.

Suzuki Mighty Boy With 440-HP V8 Is Not Your Typical Kei Car

What a beast.

Toyota Proace Camper Is A Nifty $45,800 Motorhome The US Should Get

The four converted campers mark Toyota's first participation in Spain's International Caravan Show.

More 2022 Ford Bronco Heritage Edition Details Emerge

White accents and more coming for the upcoming top-spec Bronco,

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 2887


The measurement value is OK.Possible cause and remedy



- Replace component Floor-mounted shift.



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Check fuse f55 (voltage supply from control unit ESM) in component N10/1 (Front SAM control unit with fuse and relay module).



- Check all affected plugs, connectors and electrical components for damage, loose contact, corrosion etc. and repair if necessary.



End of test



Part 2



No CAN message was received from control unit Engine management.



1.3.2.1.5. Check power supply at control unit EZS.



Test prerequisite



- Battery voltage is OK.



- Fuse F34.f36 is OK.



Status of relevant actual value:



- Power supply:Warning! Communication with ECU required.



Specified value



- Power supply [11.0...14.5] V



Question



- Is the actual value o.k.?



YES



The actual value is okay.Possible cause and remedy



- In the event of stored faults with a high fault frequency count or in the event of customer complaints, check lines and connectors for loose



contact and corrosion..



- Check alternator.



End of test



NO



The actual value is not o.k.Test sequence



- Switch off ignition.



- Detach sockets A and C at component N73 (EIS [EZS] control unit).



- Measure direct voltage with multimeter between sockets (N73) B.2 and (N73) C.1



Specified value



- Voltage [11.0...14.5] V



Question



- Are the measurement values OK?



YES



The measurement values are OK.Possible cause and remedy



- Inspect connector B,C at control unit N73 (EIS [EZS] control unit) for damage, correct connection, loose contact and corrosion and repair, if



necessary.



- N73 (EIS [EZS] control unit)



End of test



NO



The measurement values are not OK.Possible cause and remedy



- Check lines between components N73 (EIS [EZS] control unit) and N10/1 (Driver-side SAM control unit with fuse and relay module) and



repair or replace if necessary.



- Fuse and component F34 (Interior fuse box)



Continue with button F2

Manhart MHX3 600 Is Here If BMW X3 M Competition Isn't Enough

Is 503 horsepower too bland? Here you go.

Ferrari F8 Tributo Sports car

Ferrari F8 Tributo Sports car MSRP: From CAN$328040 Horsepower: 710 hp Max speed: 340 km/h Curb weight: 1435 kg Fuel economy: 16 L/100 km combined ...

2022 GMC Terrain Review, Pricing, and Specs

2022 GMC Terrain Review, Pricing, and Specs For those shopping for something that looks a bit different from the average compact crossover, the 2022 GMC ...

Friday, October 29, 2021

Ford Ranger Faces Toyota Hilux In A Pickup Truck On-Road Drag Race

A battle outside their comfort zones.

******** 奥迪TT四敞篷跑车(8J9)L4-2.0L Turbo(CCTA)技术诊断和修理#911125日 期:111129


导航系统不能出航DVD



91CD/DVD不可喷出



91 25 11



2013790/7



十一月29日至2011年。



取代的技术服务公告的组91号11-01月七月20日,2011年为的原因如下所列。



73



受影响的车辆



条件^导航或DVD的音频CD/DVD不能被喷出。



^没有Dtc储存在相应的模块。



^出按钮没被卡住。 当推动弹出按钮,驱动器没有声音,因为如果它试图退出的CD/DVD。



技术背景



车辆与DVD为基础的导航系统现在具有导航DVD期间安装的生产。 防止盗窃的DVD时



运输、退出按钮的导航驱动器是禁止的。 导航系统本身,例如路线指导作为指定。用于汽车没有导航基础的Dvd光盘,该光盘的时隙不是锁定在生产。 如果退出按钮工作如上所述,按照



该过程使弹出键作为解释如下。



生产方案



不适用的。



服务



1. 使用VAS测试启用的退出按钮的CD/DVD光盘驱动器:



接口3G/3G+



74



通过GFF,执行该试验计划,以便推出按钮通过功能/件选择>>服务的工作>>5F-出的按钮,



锁的。



接口2G通过GFF,执行该试验计划,以便推出按钮通过功能/件选择>>服务的工作>>37-出的按钮,



锁的。



RNS-E



通过GFF,执行该试验计划,以便推出按钮通过功能/件选择>>服务的工作>>J401星导航系统的。 w/CD



驱动器,使弹出按钮。



核弹出键功能是否正确。



75



担保



额外信息



所有零件和服务提供参考文献在这个TSB的情况下更改和/或清除。 总检查你的部门和服务

Toyota Invites Prospective GR86 Buyers To Test Drive The Wrong Car

Toyota goes head-to-head with the Subaru BRZ.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1722


- Test terminating resistor of CAN element in control module N3/10 (ME-SFI [ME] control unit).



End of test



3.1.3.2.2.2. Test terminating resistor of component X30/5 (Left voltage distributor (CAN) connector).



Test terminating resistor of component X30/5 (Left voltage distributor (CAN) connector).



Test sequence



- Switch off ignition.



- Connect socket box to component N3/10 (ME-SFI [ME] control unit).



- Disconnect coupling F at component N3/10 (ME-SFI [ME] control unit).



- Measure resistance with multimeter between sockets (F.41) 11 and (F.54) 24 of the 35-pole socket box tester.



Specified value



- Resistor[115...125]ohms



Question



- Is the measurement value OK?



YES



The measurement value is OK.End of test



NO



The measurement value is not OK.Possible cause and remedy



- Line from component X30/5 (Left voltage distributor (CAN) connector) to component N3/10 (ME-SFI [ME] control unit)



- Component X30/5 (Left voltage distributor (CAN) connector)



End of test



3.1.3.2.2.3. Test terminating resistor of CAN element in control module N3/10 (ME-SFI [ME] control unit).



Test terminating resistor of component N3/10 (ME-SFI [ME] control unit).



Test sequence



- Switch off ignition.



- Connect socket box to component N3/10 (ME-SFI [ME] control unit).



- Connector F is plugged in at control unit.



- Unplug the socket F from the wiring harness at the socket box.



- Measure resistance with multimeter between sockets (F.41) 11 and (F.54) 24 of the 35-pole socket box tester.



Specified value



- Resistor[115...125]ohms



Question



- Is the measurement value OK?



YES



The measurement value is OK.End of test



NO



The measurement value is not OK.Possible cause and remedy



- Control unit N3/10 (ME-SFI [ME] control unit)



End of test



3.1.3.3. Test with the aid of the measuring system



Test sequence



- Measurement of level voltage of engine CAN buses CAN bus High and CAN bus Low with the universal oscilloscope



- Separating one user from the connector strip X30/5 (Left voltage distributor (CAN) connector)



- Observe level voltage.



- Plug in connector again at connector strip X30/5 (Left voltage distributor (CAN) connector).



- Repeat this procedure for all CAN users.



Specified value



- As soon as the faulty branch was disconnected, the current image of the level voltage changes.



Possible cause of fault in the faulty branch

Loki Basecamp Icarus Truck Camper Looks Futuristic In New Photos

The camper comes with a modular interior design.

Memphis PD: Mustang Occupants Shot Corvette Driver For Refusing To Race

Unbelievable.

Ford Reveals Slammed Maverick, Lifted Rangers For SEMA Show

There's also a Maverick for beach rescues and one for the California lifestyle.

N63 Tear Down


N63 Tear Down

Ford Unveils SEMA Trucks With Grills, Sinks, And A Washing Machine

Whether you want a rugged camping rig or just to speed through the wilderness there's a truck here for you.

Ford Brings 750-HP Mustang GT, Teal EcoBoost Cruiser To SEMA Show

They won’t be arriving alone.

Ford Mustang Mach-E Gets Shelby Treatment For SEMA

It joins two other decked-out Mach-E models in Ford's booth.

******** 奥迪A6轿车(4F2)V6-3.2L(卡拉)技术诊断和修理#381105日期:110121


A/T-延迟订婚的时候冷/多DTC的设定38延迟的参与冷的时候或者没有推动在第一个参与(DTC P2700,P2701,P2702,P2703或P0730)



38 11 05



2021292/3



一月21日至2011年。



取代的技术诊断和修理小组38号10-01月19日,2010年为列出的原因如下。



受影响的车辆



条件



客户可以报告:



^在启动时,间歇性的无动在选择驱动模式或R D



^的车辆可以被驱动只能在3档(跛行的家庭模式)。



研讨会的调查结果: 在罕见的情况下,如果车辆是在运动和ATF过滤器成为松散,传输可能会进入瘸模式和可以



241



驱动中只有3齿轮。



^在寒冷的条件、变速箱班有延迟。 在炎热条件,吸气的声音发生。



^以下Dtc可以保存在传输控制单元:



^DTC P0730(传送监测不正确的齿轮比率)



^DTC P2700(离合器的一个不可信的)



^DTC P2701(离合器B令人难以置信)



^DTC P2702(离合器C难以置信)



^DTC P2703(D离合器难以置信)



技术背景因为一个设计改变,ATF过滤器可以松动,从本指南的ATF泵进气管道。 其结果是,空中可以得出的。 空



导致油泡沫,这可以防止的魔掌关闭。



生产方案



优化ATF过滤器。



服务



如果申诉可再生进行如下:



1. 检查的变速器控制单元以上的条目,并创建一个诊断协议。



^如果没有故障的存储但值得关注的可能重复;继续进行第2步。



^如果一个或多个上述故障码存储,继续步骤3的。2. 检查ATF水平每艾尔莎说明。



^如果流体水平似乎太高和泡沫状,由于空气混合ATF,继续步骤3的。



^如果流体是在正确的水平和流体是不是泡沫,打开一个技术援助中心(TAC)机票和接触的一个字代表。



3. 漏ATF入一个干净的容器和删除的ATF泛。



提示:抓住烟酒枪支弹药管理局在一个干净的容器和重复使用后修复。



4. 如果过滤器被发现在锅底,继续进行到第6步。



5. 如果过滤器仍然是固定在阀体,尝试移除它与轻武力。^当删除,如果该过滤器仍然落后密封的阀体或未完全装脖子上的过滤器,继续进行到第6步。



242



^如果密封完全安装过滤器上作为图1所示,开TAC票和接触的一个字代表。



6. 替代ATF的过滤用新的筛选根据修复手册。



注:



确保磁铁石油水池不被困在下面(侧的金属)的松散的ATF过滤器而不是去除旧过滤器。 磁铁必须重新安装在盘来保护传输从金属颗粒磨他们的正确原来的位置。



7. 如果有投诉的挡质量的替换后的ATF过滤器,清除的修改试验计划,然后执行GFF或



引导的职能适应驱动的。



243



担保



244



所需要的零件和工具



额外信息



所有零件和服务提供参考文献在这个TSB的情况下更改和/或清除。 总检查你的部门和服务

2022 Lexus LC 500 Gets Updated Suspension, Bespoke Build Customization

The starting price holds steady at $93,050.

Audi A8 L Horch Breaks Cover Ahead Of Chinese Debut Next Month

Can you spot the changes?

400-Mile 2000 Chevrolet Metro For Sale Feels Unreasonably Expensive

Who keeps a Metro this clean?

2022 GMC Sierra 1500 Review, Pricing, and Specs

2022 GMC Sierra 1500 Review, Pricing, and Specs:The 2022 GMC Sierra 1500 pickup is as capable and versatile as it ever was, but now it's considerably ...

New BMW Spy Shots Show Large SUV Testing Near The Nurburgring

The camo hides a redesigned front fascia.

Acura NSX Lines Up Against Mercedes-AMG GLC 63 For A Drag Race

It's a close finish.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 802


1051



Lambda control, before TWC left : Control implausible (P0173)



Test 1: Check self-adaptation.



Test 2: Possible cause:



- Lambda control



Affected functions:



- Engine output



1. Check self-adaptation.



Test 1.1: Check lambda control.



1.1. Check lambda control.



Test 1.1.1: Check signal from component B2/5 (Hot film mass air flow sensor) via actual value.



Test 1.1.2: Check seal of component B2/5 (Hot film mass air flow sensor) with air filter for cracks.



Test 1.1.3: Inspect air cleaner housing.



Test 1.1.4: Check component G3/3 (Left O2 sensor, before TWC [KAT]).



Test 1.1.5: Check component Y62 (Fuel injectors).



Test 1.1.6: Check exhaust system for leaks.



1.1.1. Check signal from component B2/5 (Hot film mass air flow sensor) via actual value.



Test 1.1.1.1: Check signal of component B2/5 (Hot film mass air flow sensor) via actual value with engine OFF.



Test 1.1.1.2: Check signal of component B2/5 (Hot film mass air flow sensor) via actual value with engine speed greater than 3500 rpm.



Test 1.1.1.3: Check reference signal of component B2/5 (Hot film mass air flow sensor).



1.1.1.1. Check signal of component B2/5 (Hot film mass air flow sensor) via actual value with engine OFF.



Warning!Communication with ECU required.



1.1.1.2. Check signal of component B2/5 (Hot film mass air flow sensor) via actual value with engine speed greater than 3500 rpm.



Warning!Communication with ECU required.



1.1.1.3. Check reference signal of component B2/5 (Hot film mass air flow sensor).



Test sequence



- Switch on ignition.



Status of relevant actual value:



- HFM-SFI ( Reference signal ):Warning! Communication with ECU required.



Specified value



- Reference signal[46...59] ms



Question



- Is the measurement value OK?



YES



The actual value is okay.End of test



NO



The actual value is not o.k.Possible cause and remedy

Motor1.com's Best Spy Shots Of The Week

Here's a weekly review of the vehicles that automakers don't want you to see.

Toyota bZ4X Unveiled In Production Form With FWD And AWD Versions

And an optional yoke.

Tuned Porsche 911 Turbo (992) Unleashes 900 HP On The Autobahn

186 miles per hour is not a problem for this beast.

******** Audi TTS Quattro Roadster (8J9) L4-2.0 L Turbo (CDMA) техническая диагностика и ремонт # 941292 Дата: 121024


Освещение-Накопление Влаги В Наружных Фонарях



94 наружное освещение, накопление влаги



94 12 92



2012749/11



24 октября 2012.Заменяет Бюллетень технической службы группы 94 № 11-52 от 11 октября 2011 по причинам, перечисленным ниже.



Пострадавшие Транспортные Средства



Состояние



Конденсация видна на внутренности фары, taillight, света тумана, бортового света отметки, переднего сигнала поворота, светов дневного времени идущих, или третьего тормоза



легкая линза.



техническое образование



Влажный воздух оседает на внутренности холодного объектива, который создает конденсацию.



Система циркуляции фары позволяет воздуху от снаружи пропустить через фары. Эта открытая вод-защищенная система вентиляции (необходимая длякомпенсация давления) создает различные зоны климата в фаре: очень теплые области, где объектив нагревается светом, и относительно



прохладные участки, где линза охлаждается воздушным потоком.



Значительные различия в влажности и температуре внутри и снаружи фар, даже во время движения, могут привести к



конденсация. Это особенно актуально в холодную и влажную погоду, но это также может произойти после мойки автомобиля, после паровой очистки двигателя или переднего концас ночными изменениями температуры, etc. Это явление более заметно на линзах из прозрачного стекла, чем на линзах с узорами. Влага



не влияет на работу фар (светотехника) и не приводит к коррозии или другим повреждениям деталей фар.



производственное решение



Неприменимый.



Обслуживание



Для фар, пораженная поверхность объектива должна быть ясна после приблизительно 10 минут светлой деятельности, хотя вся поверхность объектива не может



Очистить. Процесс очистки зависит от наружной температуры и влажности.В случаях, когда капли воды образовались на внутренней стороне объектива или вода собрала в нижней части световой сборки, проверьте на утечку уплотнений



и / или трещины в линзе или светлом узле. При отсутствии повреждений используйте сжатый воздух (менее 30 PSI) для очистки объектива.



На световых узлах со светодиодными огнями, например, дневные ходовые огни S6, светодиодные огни не выделяют достаточно тепла, чтобы очистить влагу от объектива. Только



перепад давления системы вентиляции обеспечивает воздушные потоки для того чтобы освободить влагу на внутренности объектива. Проектирование вентиляциисистема на этих типах светов обеспечит что объектив ясн после немного миль управлял.



Для Audi Q7, пожалуйста см. накопление влаги TSB 2028277 94 в headlamps для установки клапанов вентиляции фары. Не заменять



агрегаты света или объектива для этих условий.



4



Гарантия



Этот TSB является только информационным и не применяется к любой гарантии Audi.



дополнительная информация



Все ссылки на части и услуги, предоставленные в настоящем TSB, могут быть изменены и / или удалены. Всегда проверяйте с Вашим Dept частей. и сервисные руководства

First Look At GMC Hummer EV Accessories Debuting At SEMA

There will be nearly 200 accessories to choose from.

2022 GMC Canyon Review, Pricing, and Specs

2022 GMC Canyon Review, Pricing, and Specs: Specifications 2022 GMC Canyon AT4 VEHICLE TYPE front-engine, rear-/4-wheel-drive, 5-passenger, 4-door ...

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1461


1.1.3.2.1.4. Check power supply at control unit N15/3 (ETC [EGS] control unit).



Test 1.1.3.2.1.4.1: Guided test



1.1.3.2.1.4.1. Guided test



Operation number of operation texts and work units or standard texts and flat rates:27-0641Possible cause



- Battery has incorrect charge state or is faulty.



- Local undervoltage of component N15/3 (ETC [EGS] control unit)



Test sequence



- Erase fault memory.



Continue with button "F2"



Warning!Communication with ECU required.



1.1.3.2.1.5. Check power supply at control unit N15/5 (Electronic selector lever module control unit).



Operation number of operation texts and work units or standard texts and flat rates:27-0641Test sequence



- Switch off ignition.



- Disconnect connector at component N15/5 (Electronic selector lever module control unit).



- Switch on ignition.



- [A.2] Measure direct voltage with multimeter between 2 and 1 [A.1]



Status of relevant actual value:



- Supply voltage (tml. 15):Warning! Communication with ECU required.



Specified value



- Voltage[7.0...16.0] V



Question



- Is the measurement value OK?



YES



The measurement value is OK.Possible cause and remedy



- Replace component Floor-mounted shift.



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Check fuse f55 (voltage supply from control unit ESM) in component N10/1 (Front SAM control unit with fuse and relay module).



- Check all affected plugs, connectors and electrical components for damage, loose contact, corrosion etc. and repair if necessary.



End of test



1.1.3.2.1.6. Check power supply at control unit N15/6 (Sprintshift control module).



Test voltage supply of circuit 30.



Operation number of operation texts and work units or standard texts and flat rates:26-0641Test sequence



- Switch off ignition.



- Connect socket box to component N15/6 (Sprintshift control module).



- Measure direct voltage with multimeter between sockets (B.36) 36 and (B.38) 38 of the 126-pole socket box tester.

Mopar Heads To SEMA With 6 Wild Concepts, Vintage Jeep Ambulance

Holy guacamole – plaid seats and wood trim!

2022 GMC Acadia Review, Pricing, and Specs

2022 GMC Acadia Review, Pricing, and Specs:Text Specifications 2022 GMC Acadia AT4 VEHICLE TYPE front-engine, front/all-wheel-drive, 5–7-passenger, ...

Ferrari 612 SCAGLIETTI V12 RWD F1 COUPE

The Ferrari 612 Scaglietti (Type F137) (Italian pronunciation: [skaʎˈʎetti]) is an executive 2+2 coupé grand tourer manufactured by Italian automobile ...

Thursday, October 28, 2021

******** Audi TT Quattro Roadster (8J9) L4-2.0L Turbo (CCTA) Technical DIAGNOSIS AND REPAIR # 401004 Date: 100401


Suspension - Shock Absorber Leak Assessment Guide



40 Shock absorber leaks: assessment aid



40 10 04



2018194/4



April 1, 2010.



Supersedes Technical Service Bulletin Group 40 number 09-04 dated June 17, 2009 for reasons listed below.



Affected Vehicles



Condition



141



One or several shock absorbers have an oil coating.



Technical Background



---



Production Solution



---



Service



This information is designed to help you assess whether a shock absorber is leaking.



Leaking shock absorbers



A leaking shock absorber is characterized by a wet film of oil running down the pipe. This needs to be replaced.



Shock absorbers with oil marks



142



A light film of dried oil or oil marks on the pipe beneath the dust guard are not clear indication of a leaking shock. These are caused by residues



from filling up the shock during production or slight "condensation" in the seal area. This small amount of oil is for lubrication and reduces the wear



of the seal.



Tip: This does not affect the shock absorber. No repair is necessary.



Tip: For further information see the repair manual under "Shock absorbers, checking."



Warranty



This TSB is informational only and not applicable to any Audi warranty.



Additional Information



All parts and service references provided in this TSB are subject to change and/or removal. Always check with your Parts Department and service



manuals for the latest information.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 578


Test sequence



- Measure direct voltage with multimeter between sockets (M.80) 80 and (M.44) 44 of the 126-pole socket box tester.



- Switch on ignition.



Specified value



- Voltage[4.8...5.3] V



Question



- Is the measurement value OK?



YES



The measurement value is OK.Possible cause and remedy



- Signal wire



- B70 (Crankshaft Hall sensor)



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Lines to component B70 (Crankshaft Hall sensor)



End of test



0705



Component Y3/8s1 (Selection range sensor (VGS)) is defective.



Possible cause:



- Y3/8s1 (Selection range sensor (VGS))



Affected functions:



- Automatic transmission Function



-------------------------------------------------



Test 1: Remedial action if component 'Y3/8s1 (Selection range sensor (VGS))' is faulty



1. Remedial action if component 'Y3/8s1 (Selection range sensor (VGS))' is faulty

******** 奥迪A6Quattro轿车(4F2)V6-3.0L SC(奖)技术诊断和修理#941002日 期:100122


灯光-的许可证板灯裂/破损的/丢失的



94许可证板光破裂、破碎的、松散或失踪



94 10 02



2018740/4



一月22 2010年。取代的技术诊断和修理组94号09-17月七月2日,2009年为的原因如下所列。



受影响的车辆



条件



368



牌照灯坏了,松散或失踪。



技术背景



超过应用扭矩为装钉在生产。



生产方案



改进检查的扭矩值。



服务



如果有损害的许可证板光线上的一个侧面(见图),然后替换他们两个。



369



担保



额外信息所有零件和服务提供参考文献在这个TSB的情况下更改和/或清除。 总检查你的部门和服务

BMW to Open BMW M Driving Experience Center at Indianapolis Motor Speedway in 2022


BMW to Open BMW M Driving Experience Center at Indianapolis Motor Speedway in 2022

Ford Mondeo And Fusion Replacement Spied In Less Camouflage

This is the most revealing look yet.

BMW Battle Has M3 Comp RWD Drag Racing M3 Comp xDrive

All-wheel drive is an advantage, but it also adds weight.

2022 Mercedes-AMG SL Debuts With Fabric Roof, AWD, And V8 Power

The reinvented Sport Leicht gains rear-wheel steering and a touchscreen that tilts forward.

2022 GMC Hummer EV THE WORLD'S FIRST ALL-ELECTRIC SUPERTRUCKSGMC HUMMER EV PICKUP AND SUV

In an amazing twist of fate, General Motors' gas-guzzling Hummer brand, discontinued in 2010, is poised to make a comeback for 2022 as an all-electric ...

Motor1.com's Best Renderings Of The Week

Celebrating the talent of independent automotive designers.

Audi E-Tron Gains More Range With Software Update, But There's A Catch

It increases the usable capacity of the battery and does other powertrain tweaks.

Start Your Engines! NASCAR 21: Ignition Officially Launches, Available To Play Today

Motorsport Games' officially licensed NASCAR game arrives for PlayStation, Xbox, and PC, bringing fans our most authentic NASCAR experience to date.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 1170


REMEDY



- Disassemble and assemble automatic transmission using the repair instructions.



- Exchange electrohydraulic control unit.



IMPORTANT NOTEFollowing the repair measures, the following checks MUST be carried out using the Diagnosis Assistance System, menu



'Control unit adaptations'



- Flash programming of control unit Y3/8n4 (Fully integrated transmission control (VGS) control unit)



- SCN coding



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has open circuit.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



The measurement value is not OK.Possible cause and remedy



- Diagnostic cable has short to ground.



- Inspect wiring and connectors at connection points for loose contacts, damage and corrosion. Repair or replace as required.



End of test



NO



Further image can be displayed with key F7.X11/4 (Diagnosis test connector)Test sequence



- Switch off ignition.



- Separate plug connection at transmission.



- Measure voltage in transmission wiring harness using a multimeter.



- Measure resistance with multimeter between 3 and 11 (X11/4)



Specified value



- Resistance measured: [< 0,6] ohms



Question



- Is the measurement value OK?

Rolls-Royce Ghost Black Badge Gets 592 HP To Carry Its 100-Pound Paint Job

And we hit Miami Beach for a brief drive in the latest Black Badge model.

Ford Sierra RS500 To Return As $254,000 Continuation Model

Only three examples will be built by a UK-based firm.

2022 Ford Super Duty Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford Super Duty Review ,Exterior ,Interior ,Trims & Specs , Presentation,A 2022 Ford Super Duty—either the F-250, F-350, or F-450—is more truck than ...

2022 Honda Pilot Sport Becomes New Base Trim, LX And EX Discontinued

Meanwhile, the Pilot TrailSport will cost nearly $45,000.

2023 Mini Countryman Spied For The First Time Looking Large And In Charge

It's the gas model, but an EV has already been announced.

******** ウディTTSアトロクーペ(8J3)L4-2.0Lターボ(CDMA)技術的な診断-補 修#911125日:111129


カーナビができな取り外DVDナビ



91CD/DVDできない排出され



91 11 25



2013790/7



月29日,2011年.



がある場合、弊社にお知技術サービス紀要グループ91番号11-01月20日2011年次の場合を除きいかなる理由がある。



69



影響を受け車両



条件^ナビDVDまたはCD/DVDできない排出されます。



^DTCsの収納に対応するモジュールです。



^ジェクトボタンなった。 時を押して取り出しボタンを駆動しないというジェクトにCD/DVDします。



技術的背景



車DVD-ナビゲーションを用いたシステムのナビDVD置を製造しております。 盗難防止のDVD時



交通の取り出しボタンのドライブは無効になります。 ナビゲーションシステムとし、その道案内として機能していることを指定します。車に基づくナビ-Dvdディスクスロットがロックされていない製造しております。 場合には取り出しボタンとして動作し、上記に従



の手続きを取り出しボタンとして以下に示します。



制作のトータルソリューション



該当ありません。



サービス



1. 利用のVASテスターを取り出しボタンをCD/DVDドライブ:



MMI3G/3G+



70



を通じてGFFを行なわなければならない試験プランを取り出しボタンを機能/コンポーネントの選択>>サービス>>5F-取り出しボタンは、



ロック/ロック解除します。



MMI2Gを通じてGFFを行なわなければならない試験プランを取り出しボタンを機能/コンポーネントの選択>>サービス>>37-取り出しボタンは、



ロック/ロック解除します。



RN-E



を通じてGFFを行なわなければならない試験プランを取り出しボタンを機能/コンポーネントの選択>>サービス>>401-NAV Sysます。 w CD/



ドライブを取り出しボタンを押します。



を検証する取り出しボタンの機能が正しくです。



71



保証



追加情報



すべての部品およびサービスを参照のこTSBしに変更又は削除します。 必ず確認してくださいお部品部門、サービス

Neiman Marcus Offering GMC Hummer EV In Its Catalogue For $285,000

The perfect Christmas gift?

Aston Martin and Girard-Perregaux Collab On Racy Laureato Chronograph

For just $18,100, one of just 188 examples of this cool chronograph can be yours.

2023 Land Rover Defender 130 Patent Images Possibly Leaked

It could be 201 inches (5,105 millimeters) long.

2022 Mercedes-AMG SL Debuts Today: See The Livestream

The livestream starts at 10 AM EDT / 2 PM GMT.

19 Of 20 Small SUVs Fail To Perform In IIHS's New Side Crash Test

Only the Mazda CX-5 got a good rating. Yikes.

Richard Hammond's Restored Jaguar XK150 Now Ready To Hit The Road

The fixed-head coupe is almost back to its former glory.

2023 Mitsubishi Outlander PHEV Gets 54 Miles Of Electric-Only Range

It's an impressive figure for the redesigned SUV.

2022 Ford Mustang Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford Mustang Review ,Exterior ,Interior ,Trims & Specs , Presentation Whether it's used for top-down trips on the Sunset Strip or track time at Lime Rock, ...

2022 Ford Maverick Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford Maverick Review ,Exterior ,Interior ,Trims & Specs , Presentation。Although the nameplate originally was used on a less-than-stellar compact car line ...

Ferrari 488 Pista Overview

The 2020 Ferrari 488 Pista is the stuff of supercar dreams. Broad-shouldered with bulging fenders and a graceful arch of a roof, this confident Italian stands out ...

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 727


Possible cause:



- B4/3 (Fuel tank pressure sensor)



Affected functions:



- Engine diagnosis



-------------------------------------------------



0976



Control module has an internal error. (P0607)



Possible cause:



- Test control unit.



Affected functions:



- Engine running



-------------------------------------------------



Test 1: Test control unit.



1. Test control unit.



Test control unit.



Possible cause and remedy



- Erase fault memory and start engine.



- Reread fault memory of control unit N3/10 (ME-SFI [ME] control unit).If fault reoccurs, replace component N3/10 (ME-SFI [ME] control



unit).



Read coding and transfer to the new control unit.End of test



0981



Ignition coil primary current of cylinder 1 is too high. (P0351)



Possible cause:



- Primary current



Affected functions:



- Engine running



-------------------------------------------------



Test 1: Check component T1/x (ignition coil(s)).



1. Check component T1/x (ignition coil(s)).



Test 1.1: Check component T1/1 (ignition coil cylinder 1).



1.1. Check component T1/1 (ignition coil cylinder 1).



Warning!Hazard as a result of high voltage at the ignition system!



- Electronic ignition systems operate within a hazardous power range both at the low voltage side (primary circuit) as well as on the high



voltage side (secondary circuit).



- Contacts with such parts can result in burns, heart flutter or cardiac arrest.



Rules of conduct and protective measures



- Persons with heart pacemakers must not perform any work on the ignition system.



- Switch off the ignition when performing work on the ignition system.



- Do not touch any parts of the ignition system when starting the engine or when the engine is running.



- Wear protective shoes with rubber soles.

Wednesday, October 27, 2021

******** Audi A4セダン(8K2)L4-2.0Lターボ(CAEB)技術サービス 紀#551327日:130214


機器-低オイルレベルのメッセージ表示され



762



55石油警報DISはMMI



55 13 27



2023967/4



月14日2013年



がある場合、弊社にお知技術サービス紀要グループ55番号12-24月7日2012年の理由を記載します。



車両情報



条件"低オイルレベルのメッセージは、DISはMMIます。



技術的背景



のフードがわかるようにすることで少なくとも30秒リセットのこのメッセージを行います。 メッセージをリセットしない、DIS/MMIので



フードしていないと認められる開業により処置フードの接触のスイッチです。



制作のトータルソリューション



改良フードの接触スイッチを入れた現在の生産車両を、ソフトウェアの変更を改善したロジックを予定



生産します。



サービスチェックフードの接触のスイッチのVASの診断テスター読みMVB26のJ393のモジュールとコンポーネントをシステム制御モジュール(住所コード46)



フードは開閉選択式です。



る場合、値は変わりませんが、その後の交換のみでの接触のスイッチです。 の適用作業指示書に記載ElsaWebの交換



フードの接触のスイッチです。



ヒント:



交換しないでください完全フラッチ組立てます。 のみを交換マイクロスイッチです。



763



あるサプライヤーはB8フラッチします。 チェックの品番を現在の接触のスイッチコネクターを一番必要注:8T0953236Bは8K0953236A(図1)。



の取引先の利用にデザインの接触のスイッチ(図2)。 そのため、取り付け位置が少し異なり、異なるフード



ユピマー®uvは、三菱化学の独(図表3)。 連絡先のスイッチなクロスとの間には互換性の異なるラッチします。 しかし、ラッチを差替えて再



車両との接触のスイッチが設置されます。



^た場合の値のMVBの変化としての期待(通常運転時の接触のスイッチ)、その後は車両あるいオイルレベルの問題です。 ご確認ください油の指示に従って、修理マニュアルです。



764



保証



すべての保証に係る請求書の支払いが必要に従ってAudi保証方針や手順のマニュアルです。 請求項の対象



見直しや監査Audi保証が付いています。



必要な部品やツール



追加情報



すべての部品およびサービスを参照のこTSBしに変更又は削除します。 必ず確認してくださいお部品部門、サービス

Audi Q9 Spied Throwing Its Big Body Around The Nurburgring

Yep, Audi appears to have an even bigger crossover on the way.

'Smokey And The Bandit' Silverado Tribute Truck To Debut At SEMA

The supercharged V8 makes 700 horsepower.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 2735


- A1 (Instrument cluster)



- N3/10 (ME-SFI [ME] control unit)



- N73 (EIS [EZS] control unit)



- N47-5 (ESP and BAS control module)



- N15/3 (ETC [EGS] control unit)



- N15/5 (Electronic selector lever module control unit)



- N71 (Headlamp range adjustment control module)



- N93 (Central gateway control unit)



- N15/6 (Sprintshift control module)



- N80 (Steering column module)



- X11/4 (Diagnosis test connector)



- X63/4 (CAN databus adapter connector, 2-pin)



- Installation point of plug connection X63/4 (CAN databus adapter connector, 2-pin)



- Communication with ECU required



1.3.1.2. Wiring diagram of CAN bus



Note



- WIS is not available on this system.



- It is not possible to display the requested WIS document [ PE0019P2200TA ].



- You can start WIS on another system and display the WIS document by entering the document number [ PE0019P2200TA ] in the 'Contents'



field.



1.3.1.2. No further information available.



1.3.2. Measurements with multimeter on CAN network



Test 1.3.2.1: Voltage supply of engine compartment CAN control modules



Test 1.3.2.2: Resistance test of engine compartment CAN



1.3.2.1. Voltage supply of engine compartment CAN control modules

2023 Kia Sportage Revealed With New Design, Rugged X-Pro Trim

The interior is available with a panoramic curved display that combines the digital instrument cluster and infotainment screen

First Speed Yellow Individual G80 M3


First Speed Yellow Individual G80 M3

2022 Ford Mustang Mach-E Review ,Exterior ,Interior ,Trims & Specs , Presentation

The 2022 Ford Mustang Mach-E blends popular elements of the past and present in a highly desirable package that bodes well for the future of electric vehicles.

Top Gear Series 31 Trailer Stars F1 Drivers And Overlanding Campers

The new series premieres in November.

2023 BMW M3 CS And M4 CS Won’t Offer Manual Or RWD: Report

Sorry, purists.

******** Audi TT Quattro Roadster (8J9) L4-2.0L Turbo (CCTA) Technical DIAGNOSIS AND REPAIR # 911116 Date: 111005


Cell Phone - Poor Voice Recognition/Hard To Hear Call



91 Microphone Testing Tips



91 11 16



85



2026895/2



October 5, 2011.



Supersedes Technical Service Bulletin Group 91 number 11 - 97 dated July 15, 2011 for reasons listed below.



Affected Vehicles



Condition



Customer complains of one of the following:



^ During a Bluetooth call the other party has trouble hearing them.



^ Voice recognition accuracy is poor.



Technical Background



This TSB provides guidelines for testing microphones in a vehicle.



Production Solution



Not Applicable.



Service



1. Investigate GFF to determine if a fault is stored for microphone operation in address words 56, 5F, 67, or 77 depending on vehicle and equipment



levels.



2. If a fault is stored in GFF, proceed with the test plan outlined in the scan tool. If there is no DTC stored, proceed to step 3.



3. Verify the complaint by using one of the following methods:



a. Pair a known good compatible Bluetooth phone to the system, and place a call to a landline contact. Place the call in the same conditions as the



customer concern (driving, stationary, A/C on, etc.).



If the call quality for the other person is clear and without distortion, then the microphones are OK and should not be replaced. If noise or



distortion is heard, then proceed to step 4.



b. Create a directory contact and then a voice tag for that entry. Create the voice tag in the same conditions as the customer concern (driving,



stationary, A/C on, etc.). Playback the entry and verify it is clear and without distortion.



If the entry sounds clear, then the microphones are OK and should not be replaced. If noise or distortion is heard, then proceed to step 4.



4. Check the microphones for mechanical defects:



86



a. Remove the roof module and verify the microphones are securely seated in the roof module by pressing on them. For 2012+ C7 & D4 vehicles,



remove the microphones and inspect the rubber seal around the edge of the microphone. Verify it is not torn or broken. If it is damaged, replace



the microphone. For vehicles equipped with integrated seat belt microphones, please reference TSB 2026851, 91 Belt Microphone Overview.



Note:



When installing microphones back into the roof module, make sure the microphones are installed straight into the cavity. Installing them at any other



angle can cause damage to the microphone and/or seal.



b. Inspect the microphone wiring and verify it is securely fastened in place and that there is no visible sign of damage.



5. Check the microphones for electrical defects:



a. Disconnect the microphones and verify the voltage coming from the module is 8V +/- 10%.



b. Disconnect the microphone cable at the control module and verify that the voltage on the wiring to the microphones is 0V.



c. If voltage is present in step a. and step b., then inspect the wiring for any shorts.



d. If voltage is not present in either case, or the incorrect voltage was measured in step a., then inspect the control module for proper output



voltage at the module and replace if necessary.



e. If both step a. and step b. were OK, then replace the microphones.



Warranty



This TSB is informational only and not applicable to any Audi warranty.



87



Additional Information



The following Technical Service Bulletin(s) will be necessary to complete this procedure:



^ TSB 2026851, 91 Belt Microphone Overview



^ TSB 2026888, 91 Bluetooth Phone: poor call quality



^ TSB 2027718, 91 Bluetooth Phone: call quality poor at other end



All parts and service references provided in this TSB are subject to change and/or removal. Always check with your Parts Department and service



manuals for the latest information.

BMW X5 vs Range Rover Sport vs Porsche Cayenne S Coupe by Rybrook TV


BMW X5 vs Range Rover Sport vs Porsche Cayenne S Coupe by Rybrook TV

2022 Ford Ranger Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford Ranger Review ,Exterior ,Interior ,Trims & Specs , Presentation 2022 Ford Ranger SuperCrew Safety Technology Pre-Collision Assist This is Ford's ...

Most Expensive 2022 Land Rover Range Rover Costs $183,150

The price could climb even higher with dealer-installed accessories.

Mercedes-Benz Sustaineer Concept Is The Delivery Van Of The Future

It has a massive solar cell on the roof that can add thousands of miles a year in range.

Mike Flewitt Steps Down As McLaren CEO, Brand Is Searching For Successor

After eight years with the British company.

Ford Mustang Mach-E And Hyundai Ioniq 5 Ace Euro NCAP Crash Test

A few conventional models also received five-star ratings.

FIA Presidential Candidate ben Sulayem On His Plans To Double Motorsport

If successful, Ben Sulayem would be the first non-European to lead the FIA.

Drag Race: BMW M3 xDrive vs RWD – by Carwow


BMW M3 xDrive vs RWD: DRAG RACE

2022 Ford GT Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford GT Review ,Exterior ,Interior ,Trims & Specs , Presentation .For anyone who wants to drive a race car that's legal for road use, just gather up about a ...

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 2761


Test voltage supply of circuit 30.



Test sequence



- Measure direct voltage with multimeter between sockets [ F.2 ] 98 and [ F.16 ] 112 of the 35-pole socket box tester.



- Switch on ignition.



Specified value



- Voltage[11.0...15.0] V



Question



- Is the measurement value OK?



YES



The measurement value is OK.End of test



NO



The measurement value is not OK.Possible cause and remedy



- N10/1f57 (Fuse 57)



- Lines



End of test



1.3.2.1.1.2. Test current consumption of component N10/1kR (Circuit 87 relay, engine).



Connect socket box to component N3/10 (ME-SFI [ME] control unit).

2022 Mercedes-AMG SL Final Teaser Hypes Up October 28 Reveal

We don't say this too often, but a new SL is finally (almost) here.

2024 Range Rover EV Could Run On Hydrogen

A battery-powered model also remains in the cards.

Pagani Zonda C12S Crashed In The Czech Republic Is Not A Pretty Sight

It cost $350,000 back in the day, probably a lot more now. Well, maybe not this one...

These Cars Retain Their Value Best After Five Years

The used car market is going crazy, a new study reaffirms.

Mazda MX-5 990S Special Edition For Japan Weighs Only 2,182 LBS

It's almost as light as the original Miata NA.

******** Audi A5 Cabriolet (8F7) L4 2.0 L Turbo (CAEB) Techniques de DIAGNOSTIC ET de RÉPARATION # 571160 Date: 111021


Keyless Systèmes Clé En Mémoire Les Paramètres Ne Sont Pas Disponibles



57 Personnalisée des paramètres de la mémoire de la clé ne sont pas disponibles



57 11 60



2019958/6



Le 21 octobre 2011.Remplace Techniques de DIAGNOSTIC ET de RÉPARATION du Groupe 57 10 - 35 en date du 18 octobre 2010 pour les raisons énumérées ci-dessous.



289



Véhicules Concernés



Condition



Le client peut signaler que personnalisée des paramètres de la mémoire (par exemple, électrique des rétroviseurs extérieurs, mémoire pour le siège, radio, climatisation, électricité



volant, etc.) sont inopérantes ou incorrectement attribué lors de l'utilisation de la touche de la télécommande.



De Formation Technique



Les paramètres de la mémoire pour chaque clé sont stockés dans le contrôle individuel de l'unité (selon la fonction) et non pas dans la clé elle-même.Seuls l'identification de la actuellement utilisé à distance de la clé est transmise sur le bus can. Chaque participant de l'unité de contrôle établit ses propres réglages.



La Solution De Production De



Non applicable.



Service



Pour écarter la clé de la cause, vérifiez si la touche de la télécommande est correctement identifié par le véhicule.



Astuce: des clés sur les positions 1 à 4 sont inclus dans l'personnalisée des paramètres de la mémoire de fonctions. Les clés de la position 5 ne peut pas être personnalisé.



^ A3, TT, R8: Vérifier MVB 10 dans le confort unité de commande (adresse de mot 46).^ A4 (B7), A4 Cabriolet: Vérifier MVB 7 dans le confort unité de commande (adresse de mot 46).



^ A4 (B8), A5, Audi Q5: Vérifier MVB 10 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A6 (C6), Audi Q7: Vérifier MVB 11 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A8 (D3): Vérifier MVB 6 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



^ A6 (C7), A8 (D4): Vérifier MVB 10 dans l'unité de contrôle d'accès/autorisation de démarrage (adresse mot 05).



290Si l'identification de la clé est affichée correctement, la clé est l'exploitation aux spécifications du fabricant.



La cause de la condition doit donc être trouvé dans l'un des participants, des unités de contrôle.



Garantie



Cette BST est d'information uniquement et ne s'applique à aucune garantie Audi.



Des Informations Supplémentaires



Toutes les pièces de service et les références fournies dans ce BST sont sujettes à modification et/ou suppression. Toujours vérifier auprès de votre Département des Pièces et service

2023 Kia Sportage For The US Debuts Today: See The Livestream

The livestream starts at 2:00 PM EDT.

Ferrari 812 Super fast

For some reason, the auto industry loves alphanumeric model names, even though many of them don't make sense and are less memorable than the perfectly ...

Tuesday, October 26, 2021

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 385


- Y62y3 (Fuel injector cylinder 3)



1.1.4. Inspect component Y62y3 (Fuel injector cylinder 3) for leaks.



Figure legend



- A -ConnectionTest cable 35-pin socket box



- 001 -Sockets of component N3/10 (ME-SFI [ME] control unit)



- 05 -35-pin socket box



- 050 -126-pin socket box



- 108 -Test cable 266 589 01 63 00



- N3/10 (ME-SFI [ME] control unit)



- II 1-63ConnectionTest cable



- III 64-126ConnectionTest cable



Warning!



- Connection A of test cable 108 may NOT be connected to connection B of the 126-pin socket box (050).



Continue to test with button F2



Figure legend



- 055Measuring beakerY62 (Fuel injectors)



Test sequence



- Switch off ignition.



- Remove fuel rail together with component Y62y3 (Fuel injector cylinder 3).



- Bridge between sockets (F.4) 100 and (F.17) 113 of the 126-pole socket box tester.



- Switch on ignition.



Specified value



- Component Y62y3 (Fuel injector cylinder 3) must not drip.

Handbücher für die neuesten Informationen.******** Audi A4 Limousine (8K2) L4-2.0 L Turbo (CAEB) Technical Service Bulletin # 911250 Datum: 120801


Handy - Schlechte Bluetooth(R) Anruf-Qualität



91 Bluetooth-Telefon: schlechte Qualität



91 12 50



2026888/3



1.August 2012.



Ersetzt Technical Service Bulletin-Gruppe 91 Nummer 11 - 21 datiert 24. Oktober 2011 für die nachfolgend aufgeführten Gründen.



Betroffene Fahrzeuge



Zustand



Kunde beschwert sich eines der folgenden während eines Telefonats:



- Echo-Effekt



- Fahrer oder andere party nicht, Konversation hören



- Sound Verzerrung oder feedback



- Der Klang ist verzerrt, rauscht oder kratzt



Technischer HintergrundDieses bulletin enthält Richtlinien für die Analyse der Qualität der Bluetooth-system im Fahrzeug.



Es gibt mehrere Faktoren, die die Qualität innerhalb eines Fahrzeugs:



^ Innenraum Geräusche



^ Die Qualität eines Bluetooth-Anruf wird direkt an das signal-Rausch-Verhältnis. Elemente, die Einfluss auf dieses Verhältnis sind:



Unterschiedliche Fahrbahn/Reifen.



Öffnen Sie Fenster oder Schiebedach.



Klimaanlagen-fan-speed-und entlüften position.



^ Körpergröße/Sitzposition



^ Abweichungen in Kunden-Höhen - /Sitz-position ändert sich der Abstand der Mikrofone und damit die Empfangsqualität.



^ Handy-Empfang und-Anbieter



95^ Reduziert Rezeption vorstellen können, Lärm in der Bluetooth-Anruf. Empfang display auf dem Telefon ist ein Indikator, aber keine genaue



Darstellung der tatsächlichen Rezeption.



^ Telefon-Anbieter vorstellen Rauschunterdrückung in Ihr system zu erhöhen, die Qualität. Diese Unterdrückung kann die call-sound dünner, und in



zusammen mit der hohen inneren Geräusche, hat eine Compoundierung negative Auswirkungen auf die Klangqualität.



^ Technische Probleme



Produktion Lösung



Nicht Anwendbar



Service1. Bei der Analyse von Bluetooth-Anruf-Qualität Beschwerden, versuchen zu sammeln so viele Informationen wie möglich aus den Kunden als Hilfe bei der Diagnose.



Die Fragen sind:



^ Kunde das Handy-Modell und aktuelle software. Überprüfen Sie die Telefon-und software-kompatibel mit www.audiusa.com/bluetooth. Wenn das Handy aus ist



nicht kompatibel, ein bekannter kompatiblen Telefon verwendet werden kann für Diagnose-Zwecke, um zu beweisen das system ordnungsgemäß funktioniert.



^ Was Problem ist, die Kunden erleben mit dem Bluetooth-Anruf?



Echo?



Kein Ton? Thema erfahrene Fahrer oder eine andere person?Sound ist zu leise? Thema erfahrene Fahrer oder eine andere person?



Verzerrt audio? Thema erfahrene Fahrer oder eine andere person?



^ Wie oft muss die Beschwerde eintreten?



^ Scheint da zu sein, die auf irgendein Muster, um die Kunde von Aktionen, bevor die Beschwerde kommt?



2. Je nach Beschwerde durch den Kunden bereitgestellten, gehen Sie zum entsprechenden Schritt.



^ Echo



MMI 3G/3G+:



^ Prüfen und/oder ersetzen Handy.



^ System-Architektur erlaubt nicht, das echo zu treten. Sie ersetzt nicht eine Steuerung für einen echo Anliegen.



UHV KÖNNEN, MMI 2G:^ Reduzieren call-Volumen (auf dem Handy und/oder das Fahrzeug).



^ Wenn echo tritt bei jedem Anruf, das Telefon zurücksetzen oder ersetzen, wenn nötig.



^ Wenn das echo tritt immer auf den gleichen Strecken oder immer ein, wenn Sie die gleiche person sind, kann dies abgeleitet werden, die als Empfangs-oder



carrier-Problem ist und nicht das Fahrzeug.



^ Wenn echo nicht reduziert werden unter Verwendung der obigen Methoden/Erklärungen, prüfen und/oder ersetzen Sie das UHV-Steuergerät.



^ Kein Ton



Für die andere person auf der Linie:



^ Prüfen und/oder ersetzen Sie das Mikrofon.



^ Prüfen und/oder ersetzen Handy.^ Wenn der Ton nicht korrigiert werden unter Verwendung der obigen Methoden/Erklärungen, prüfen und/oder ersetzen Sie das UHV-Steuergerät.



Für den Fahrer:



^ Mikrofone haben keinen Einfluss auf die Lautstärke/Qualität für Fahrer und ausgeschlossen werden kann.



^ Prüfen und/oder ersetzen Handy.



96



^ Überprüfen Sie die Verdrahtung vom UHV an Radio KANN in Fahrzeugen.



^ Wenn der Ton nicht korrigiert werden unter Verwendung der obigen Methoden/Erklärungen, prüfen und/oder ersetzen Sie das UHV-Steuergerät.



^ Fordert, sind zu leise



Für die andere person auf der Linie:



^ Andere person erhöhen der Lautsprecher-Lautstärke.



^ Prüfen und/oder ersetzen Sie das Mikrofon.^ Für 3G & 3G+ Fahrzeuge: einstellen der Mikrofon-Empfindlichkeit.



Tipp: das Einstellen der Mikrofon-Empfindlichkeit KÖNNEN Fahrzeuge wird nicht empfohlen, da dies kann die anderen Fahrzeug-features, wie z.B. Voice



Anerkennung und Audio-Pilot.



Für den Fahrer:



^ Erhöhen Sie die Lautstärke im Fahrzeug.



^ Erhöhen Sie die Lautstärke am Handy (wenn erlaubt vom Handy-Modell).



^ Anrufe sind verzerrt



^ Reduzieren Sie die Lautstärke am Handy (wenn erlaubt vom Handy-Modell).



^ Verringern Sie die Lautstärke.



^ Löschen Bluetooth-Verbindung auf dem Telefon und Fahrzeug-und re-pair-Mädchen.



^ Reset Mikrofon-Empfindlichkeit.^ Überprüfen Sie die position der Lüftungsdüsen und die Intensität des Gebläses ist nicht die Ursache Mikrofon Störungen.



Garantie



Diese TSB ist nur zu Informationszwecken und nicht für alle Audi-Garantie.



Weitere Informationen



Die folgenden Technischen Service-Bulletin(s) Ihnen weitere Informationen:



^ TSB 2026851, 91-Gürtel-Mikrofon Übersicht



^ TSB 2026895, 91 Mikrofon-Tests-Tipps



^ TSB 2027718, 91 Bluetooth-Telefon, die Qualität der Armen am anderen Ende



Alle Teile und service-Verweise in dieser TSB unterliegen, zu ändern und/oder entfernen. Überprüfen Sie immer mit Ihrem Teile-und service-AbteilungHandbücher für die neuesten Informationen.

Alpina B4 Gran Coupe Spy Pics Show Car With More Camo Than Before

It hides Alpina’s subtle styling touches.

Alpha Tauri F1 Team Drove The Wheel (Cap) Off Of An Original NSX

And we have the picture to prove it.

HPD Civic Si Race Car Prototype Joins Other Cool Honda Builds At SEMA

Amid new Si projects are SUVs, trucks, and a Type R-powered '90s Accord wagon.

Miura Speedboat With Two Lamborghini V12 Engines Heading To Auction

Imagine how amazing this watercraft must sound.

Stealth Brands Hatch Grey F90 M5 Photoshoot


XPEL Stealth Brands Hatch Grey F90 M5 airport pics

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 598


- Voltage[11.0...15.0] V



Question



- Is the measurement value OK?



YES



The measurement value is OK.Further possible causes of fault



- Signal wire



- B6/5 (Right intake camshaft Hall sensor)



End of test



NO



The measurement value is not OK.Possible cause and remedy



- N10/1f43 (Fuse 43)



- N10/1kI (Circuit 87 relay, engine)



- Lines to component B6/5 (Right intake camshaft Hall sensor)



End of test



1.3. Check assignment of signals from Hall sensors 'Camshafts' and 'Crankshaft'.



Check assignment of signals from Hall sensors 'Camshafts' and 'Crankshaft'.



Figure legend



- A -ConnectionTest cable 35-pin socket box



- 001 -Sockets of component N3/10 (ME-SFI [ME] control unit)



- 05 -35-pin socket box



- 050 -126-pin socket box



- 108 -Test cable 266 589 01 63 00



- N3/10 (ME-SFI [ME] control unit)



- II 1-63ConnectionTest cable



- III 64-126ConnectionTest cable



Warning!



- Connection A of test cable 108 may NOT be connected to connection B of the 126-pin socket box (050).



Continue to test with button F2



Figure legend



- 1Signal from component B6/5 (Right intake camshaft Hall sensor)

Mini Shadow Edition Models Arrive To Create A Stealthy, Little Car

You can even get this darker look on the electric Mini.

Dodge Challenger R/T Scat Pack Blasts Down Autobahn At 166 MPH

Listen to that angry American V8 rumble.

2023 Chevrolet Corvette Z06 Revealed: 670 HP Monster Revs To The Moon

Its naturally aspirated V8 is the most powerful ever used in a production car.

Attacking The Dragon’s Tail in a 2022 X3M


Attacking The Dragon’s Tail in a 2022 X3M

******** Audi S5 Quattro Coupe (8T3) V8-4,2 L (CAUA) Technische DIAGNOSE-UND REPARATUR # 371238 Datum: 120222A/T - DTC-00230, Schlüssel Steckte, Fahrzeug nicht Verriegeln

BMW’s 10 Way Traction Control System Tested


BMW’s 10 Way traction control system tested by Joe Achilles

Dodge Charger, Challenger Styling Packs Prep Models For Halloween

Pick either the Hemi Orange or the SRT Black appearance package.

2022 Ford Edge Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford Edge Review ,Exterior ,Interior ,Trims & Specs , Presentation.If you're looking for a medium-sized SUV but don't need three rows of seats, the 2022 ...

Hyundai Palisade Facelift Rendering Takes After The Latest Spy Shots

Significant tweaks are to be expected.

BMW i4 Owners Manual and Navigation Guide


BMW i4 Owners Manual and Navigation Guide

Audi RS7 With Akrapovic Exhaust Sounds Delightfully Raw In Autobahn Run

Yummy!

Porsche Cayenne Facelift Spied With Weird Taillights

Of course, this is not what the production clusters will look like.

2022 Range Rover Debuts Today: See The Livestream

The livestream starts at 3:25 PM / 7:25 PM.

Opel Insignia Shows Good Results In Motor1.com Moose Test

The D-segment model rides on 18-inch wheels.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 597


0755



B6/5 (Right intake camshaft Hall sensor) : The alternation frequency of the signal value is implausible. (P0341)



Possible cause:



- B6/5 (Right intake camshaft Hall sensor)



Affected functions:



- Engine diagnosis



- Engine output



-------------------------------------------------



Test 1: Check component B6/5 (Right intake camshaft Hall sensor).



1. Check component B6/5 (Right intake camshaft Hall sensor).



Test 1.1: Check component B6/5 (Right intake camshaft Hall sensor) using actual value.



Test 1.2: Check power supply of component B6/5 (Right intake camshaft Hall sensor).



Test 1.3: Check assignment of signals from Hall sensors 'Camshafts' and 'Crankshaft'.



1.1. Check component B6/5 (Right intake camshaft Hall sensor) using actual value.



Warning!Communication with ECU required.



1.2. Check power supply of component B6/5 (Right intake camshaft Hall sensor).



Test prerequisite



- The actual value is not o.k.



Test sequence



- Switch off ignition.



- Detach coupling at component B6/5 (Right intake camshaft Hall sensor).



- [ B6/5 ]Measure direct voltage with multimeter between sockets 1 and 3[ B6/5 ]

See 2022 Audi RS3 Sedan Hit 62 MPH (100 KM/H) In Only 3.1 Seconds

It's just as quick as the Ferrari Enzo, a full-blown V12 hypercar.

******** Audi A8 Quattro Limousine (4E2) V8-4,2 L (BVJ) Technische DIAGNOSE-UND REPARATUR # 641224 Datum: 120824


Körper - Vordere Fenster Schleifen Oder Quietschen Beim Gehen Nach Oben/Unten



64 Lärm beim Betrieb Frontscheibe



64 12 24



30



2030561/1



August 24, 2012.



Betroffene Fahrzeuge



ZustandDer Kunde kann Bericht Schleif-oder Quietschgeräusche beim betätigen der vorderen Tür-Fenster oben/unten (Abbildung 1).



Technischer Hintergrund



In einer Anstrengung, um Informationen über die Geräusche, die für die Fahrzeuge die oben aufgeführt sind, bitten wir, Sie Kontakt mit der Audi-Technical Assistance Center



(TAC) vor dem Auswechseln der Teile. Dies wird uns helfen, bei der Diagnose, um potenzielle Probleme mit der Bedingung oben erwähnt.



Produktion Lösung



Keine änderungen an der Produktion vorgenommen wurden, kein Problem identifiziert.



ServiceAudi of America um Ihre Zusammenarbeit in der Versorgung der uns mit technischen Informationen in Bezug auf diese Bedingung. Wenn das Fahrzeug innerhalb der Neuen



Fahrzeug-Garantie, Kontaktieren Sie einen TAC-Berater, bevor Sie fortfahren.



Garantie



Diese TSB ist nur zu Informationszwecken und nicht für alle Audi-Garantie.



Weitere Informationen



Alle Teile und service-Verweise in dieser TSB unterliegen, zu ändern und/oder entfernen. Überprüfen Sie immer mit Ihrem Teile-und service-Abteilung

Skoda Fabia Wagon Officially Dead Due To Stricter Emissions Regulations

Fewer ICEs, more EVs. You know the drill...

2023 Chevy Corvette Z06 Debuts Today: See The Livestream

The livestream starts at 12 PM EDT / 4 PM GMT.

2022 Ford F-150 Lightning Review ,Exterior ,Interior ,Trims & Specs , Presentation

2022 Ford F-150 Lightning Review ,Exterior ,Interior ,Trims & Specs , Presentation Ford hasn't kept the upcoming F-150 Lightning a secret, evidenced by the ...

Ferrari Scuderia Spider Engine: 4.3L V8 / Power: 503 bhp @ 8,500 rpm / Torque

2009 – 2010 Ferrari Scuderia Spider 16M Year(s): 2009-2010 / Engine: 4.3L V8 / Power: 503 bhp @ 8500 rpm / Torque: 347 lb/ft @ 5250 rpm / Power to Weight: ...

Monday, October 25, 2021

******** Audi S5 Quattro Coupe (8T3) V8-4.2L (CAUA) Technical DIAGNOSIS AND REPAIR # 481230 Date: 120625


Steering - Steering Wheel Leather Damage



48 Steering wheel leather damage, all vehicles



48 12 30



2028220/2



June 25, 2012



Supersedes Technical Service Bulletin Group 48 number 11 - 18 dated December 7, 2011 for reasons listed below.



Affected Vehicles



Condition



Steering wheel damaged.



Technical Background



59



Optical damage on the steering wheel (Figures 1 and 2) is not warrantable. Numerous investigations have shown that there is no fault in material or



workmanship. The damage is caused by external impact, e.g. contact with finger nails, zippers, watches, rings etc.



Production Solution



Not Applicable.



Service



Not Applicable.



Warranty



This damage is due to outside influence and is not covered by any Audi warranty.



Additional Information



All parts and service references provided in this TSB are subject to change and/or removal. Always check with your Parts Department and service



manuals for the latest information.

2010 Mercedes Benz C 300 (204.054) V6-3.0L (272.947) Page 525


- Engine running



Test sequence



- Briefly blip throttle.



Status of relevant actual value:



- Coolant temperature:Warning! Communication with ECU required.



- Knock control enable:Warning!



Specified value



- Knock control enable:YES



Question



- Is the actual value o.k.?



YES



The actual value is okay.End of test



NO



The actual value is not o.k.Possible cause and remedy



- Lines to component A16/1 (knock sensor 1, right)



- Component A16/1 (knock sensor 1, right)



End of test



0502



Component A16/1 (knock sensor 1, right) has a short circuit to ground. (P0327)



Possible cause:



- A16/1 (knock sensor 1, right)



Affected functions:



- Engine running



-------------------------------------------------



Test 1: Check component A16/1 (knock sensor 1, right).



1. Check component A16/1 (knock sensor 1, right).



Test prerequisite



- Engine running



Test sequence



- Briefly blip throttle.



Status of relevant actual value:



- Coolant temperature:Warning! Communication with ECU required.



- Knock control enable:Warning!



Specified value



- Knock control enable:YES



Question



- Is the actual value o.k.?



YES



The actual value is okay.End of test



NO



The actual value is not o.k.Possible cause and remedy



- Lines to component A16/1 (knock sensor 1, right)



- Component A16/1 (knock sensor 1, right)

New Toyota EV Tops Out At 15 MPH And Is Only Useable At Airports

The tractor comes from Toyota Industries Corporation.

Classic Range Rover Restomod Will Make You Forget About The New One

If you can afford it.

Pre-Production BMW iX in Depth Walkaround and Showcase


Pre-Production iX in depth walk-around and showcase

2022 Dodge Charger Review ,Exterior ,Interior ,Trims & Specs , Presentation

Specifications 2022 Dodge Charger Review ,Exterior ,Interior ,Trims & Specs , Presentation VEHICLE TYPE: front-engine, all-wheel-drive, 5-passenger, 4-door ...

Lamborghini Huracan STO Hits 200 MPH With Ease On The Autobahn

It sounds amazing and offers incredible performance.

Shaq Arrived At US Grand Prix In A Crazy Custom Cadillac With Horns

A massive car for a massive man.

New Audi Q6 E-Tron Spy Pics Provide Up-Close Look At Crossover

The cover comes off sometime next year.

‘MM’ California License Plate Costs An Insane $24.5 Million

It's tied to an NFT

Pre-Production BMW i4 in depth walk-around and showcase


Pre-Production BMW i4 in depth walk-around and showcase

******** Audi A4 Quattro Limousine (8K2) L4-2.0 L Turbo (CAEB) Technical Service Bulletin # 971233 Datum: 120605


Audi A4 Quattro Limousine (8K2) L4-2.0 L Turbo (CAEB) Seite 116



Audio-System - iPod(R)/USB Nicht Erkannt Oder Geladen



91 MMI3G: iPod oder USB-Gerät nicht erkannt oder geladen



97 12 33



2021037/6



Juni 5, 2012.



Ersetzt Technical Service Bulletin-Gruppe 97, Nummer 11 - 28 vom November 23, 2011 für die nachfolgend aufgeführten Gründen.Betroffene Fahrzeuge



Zustand



Der iPod oder der USB-stick wird nicht erkannt, oder der iPod wird nicht aufgeladen, wenn entweder Gerät angeschlossen ist an das Audi Music Interface (AMI).



Technischer Hintergrund



Kann eine der folgenden anwenden:



^ iPod und adapter-Kabel verbunden sind in der falschen Reihenfolge.



^ Das adapter-Kabel nicht mit dem Anschluss verbunden, weil der port nicht korrekt in der glove-box Gehäuse.



^ Der Kabelbaum für AMI zwischen die MMI-Steuereinheit (5F) und der Anschluss für den adapter-Kabel ist beschädigt.



Produktion Lösung



Nicht anwendbar.



Service1. Trennen Sie den iPod und den adapter-Kabel.



ein. Schließen Sie das Adapterkabel an den Anschluss im Handschuhfach Gehäuse. Adapter-Kabel sollte mit einem klicken einrasten. Wenn nicht, gehen Sie zu Schritt 2.



b. Schließen Sie den iPod an den adapter-Kabel.



c. Wenn der iPod erkannt wird, erklären, die Verbindung zu den Kunden.



Audi A4 Quattro Limousine (8K2) L4-2.0 L Turbo (CAEB) Seite 117



d.... Die Verbindung Prozess gilt nicht für den USB-stick.



2. Installieren Sie die Anschluss-Stecker im Handschuhfach-Gehäuse.



ein. Schließen Sie das Adapterkabel an den Anschluss.



b. Schließen Sie den iPod oder USB-memory-stick.3. Retest mit einem bekannt guten USB-memory-stick, iPod und adapter-Kabel.



4. Wenn die Beschwerde ist nicht gelöst mit den Schritten 1 - 3, überprüfen Sie den AMI-Kabelsatz für die Kontinuität und shorts.



Ersetzen, wenn nötig.



Der original-Kabelbaum kann im Fahrzeug verbleiben, es muss aber geschützt werden, von Rasseln gegen andere Komponenten.



Audi A4 Quattro Limousine (8K2) L4-2.0 L Turbo (CAEB) Seite 118



Garantie



Erforderliche Teile und Werkzeuge



Weitere Informationen



Alle Teile und service-Verweise in dieser TSB unterliegen, zu ändern und/oder entfernen. Überprüfen Sie immer mit Ihrem Teile-und service-AbteilungHandbücher für die neuesten Informationen.

New BMW M4 CSL Sounds Menacing In Nurburgring Spy Video

It could offer 540 horsepower.

Pre-Production iDrive 8 System Demo


iDrive 8 system sneak peak
